12" Wide 230V 2-Burner Radiant Cooktop - CR2B23T3B

SummitSummit brand logo
This product has been discontinued by the manufacture and is no longer available.

12" Wide 230V 2-Burner Radiant Cooktop

Model: CR2B23T3B

12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
+3more

Color : Black

12" Wide 230V 2-Burner Radiant Cooktop CR2B23T3B
Black

Key Features

  • Large 1800W burner

  • Residual heat indicator lights

  • Standard 1200W burner

  • Digital touch controls

  • 9 power levels

  • Designed for built-in installation

  • ADA compliant design

  • Timer

Read More

Description

Summit's collection of smooth-top radiant cooktops offers an easy-to-clean design with modern style built for smaller kitchen spaces. The CR2B23T3B is an ENERGY STAR certified 12" wide 230V radiant cooktop designed to fit popular 10 3/4" W x 19 7/8" D counter cutouts. Its surface is made of jet black glass for a contemporary look that's easier to clean. This unit does not ship with a power cord and must be hard-wired by a professional. For true cooking versatility, the CR2B23T3B features a large 7" 1800W burner in the rear and a smaller 5 1/2" 1200W burner in front. The digital touch controls are located in the front for easier accessibility, preventing users from reaching over hot burners to make adjustments. Nine power levels provide true cooking versatility, allowing you more precision in melting or simmering at a low wattage and the convenience of boiling water quickly at a higher setting. The digital display makes it easy to read and manage the settings at the touch of a button. This unit also includes a timer function that lets you program a power level and cook time (up to 99 minutes). The burner turns off automatically when the cooking duration has finished. Safety features include a child lock function, automatic shutoff, and residual heat indicators for both elements. With its attractive design, ideal size, and intuitive touch controls, the CR2B23T3B brings a user-friendly cooking performance with reliable safety to small kitchen spaces.
Read More

Available from AM Direct Appliances INC, serving customers throughout Illinois,Arizona, Indiana, WI.

Features
Specifications

Features

Large 1800W burner

Rear 7" burner offers 1800W for faster heating of larger cooking vessels

Residual heat indicator lights

Each burner includes a residual heat indicator to warn users if the surface is still too hot to touch

Standard 1200W burner

Front burner is 5.5" in diameter to meet most cooking needs

Digital touch controls

Easy operation with a digital control panel and digital display

9 power levels

Select and adjust your heating levels at the touch of a button

Designed for built-in installation

Fits counter cutout sizes that are 10.75" wide by 19.9" deep

ADA compliant design

Upfront controls meet ADA guidelines for easier accessibility

Timer

Allows you to program either burner to heat at a specified level for up to 99 minutes

Child lock

Safety feature lets you lock the cooktop to prevent unsupervised heating

Automatic shutoff

If a cooking zone is in use for over two hours with no changes to the control setting, the burner will automatically turn off to prevent unsupervised heating

Safety cut-off function

If the cooktop on/off switch is touched but no power level is selected within one minute, the cooktop automatically turns off

230V operation

Requires professional hardwired installation to 230V power supply

ENERGY STAR certified

Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs

2-Burner Radiant Cooktop

230V cooktop with digital controls and a smooth glass surface

Jet black glass surface

Elegant style on a smooth, jet blaack glass surface for a contemporary look that is easier to clean

Specifications

Warranty

Parts1 Year
Labor1 Year

Dimensions & Weight

Width11.38 in.
Height2 in.
Length20.5 in.
Weight10 lbs.

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement0.27 ft³
Dimensional Weight2.81 lbs.
Total of Cubes0.27 ft³
Total of Dimensional Weight2.81 lbs.

Overview Electric Cooktop

Nominal Height2.0" (5 cm)
Height of Cabinet2.0" (5 cm)
Nominal Width12.0" (30 cm)
Width11.38" (29 cm)
Nominal Depth21.0" (53 cm)
Depth20.5" (52 cm)
CabinetBlack
US Electrical SafetyETL
Canadian Electrical SafetyETL-C
Amps15.0
Voltage/Frequency230 V AC/60 Hz
Weight10.0 lbs. (5 kg)
Parts & Labor Warranty1 Year
UPC761101053295
Heating TypeRadiant
SurfaceGlass
Element TypeGlasstop
Number of Elements2
ControlsDigital
Cooking TimerYes
Countertop Cutout Height5.9" (15 cm)
Countertop Cutout Width10.75" (27 cm)
Countertop Cutout Depth19.9" (51 cm)
Power Source230V
Element #1 Size7.0" (18 cm)
Element #1 Wattage1800.0
Element #2 Size5.5" (14 cm)
Element #2 Wattage1200.0
Power Cord IncludedNo
Auto Shutoff Time2 Hours
